_pg_setpalette



Synopsis : #include <pgchart.h>

              short _FAR _pg_setpalette( paletteentry _FAR *pal );



Description : The _pg_setpalette function sets the internal palette of the presentation graphics system. The palette controls the colors, line styles, fill patterns and plot characters used to display each series of data in a chart.

The argument pal is an array of palette structures containing the new palette. Each element of the palette is a structure containing the following fields:

fields	Meaning
color	color used to display series
style	line style used for line and scatter charts
fill	fill pattern used to fill interior of bar and pie sections
plotchar	character plotted on line and scatter charts



Returns : The _pa_setpalette function returns zero if successful; otherwise, a non-zero value is returned.





See Also : _pg_defaultchart, _pg_initchart, _pg_chart, _pg_chartpie, _pg_chartscatter, _pg_getpalette, _pg_resetpalette



Example :

#include <graph.h>

#include <pgchart.h>

#include <string.h>

#include <conio.h>



#define NUM_VALUES     4

char _FAR *categories[NUM_VALUES] = { "Jan", "Feb", "Mar", "Apr" };

float values[NUM_VALUES] = { 20, 45, 30, 25 };

char bricks[8] = { 0xff, 0x80, 0x80, 0x80, 0xff, 0x08, 0x08, 0x08 };

main( )

{

    chartenv     env;

    palettetype   pal;

    _setvideomode( _VRES16COLOR );

    _pg_initchart( );

    _pg_defaultchart ( &env, _PG_COLUMNCHART, _PG_PLAINBARS );

    strcpy( env.maintitle.title, "Column Chart" );



    /* get default palette and change 1st entry */

    _pg_getpalette( &pal );

    pal[1].color = 12;

    memcpy( pal[1].fili, bricks, 8 );



    /* use new palette */

    _pg_setpalette( &pal );

    _pg_chart( &env, categories, values, NUM_VALUES );



    /* reset palette to default */

    _pg_resetpalette( );

    getch( );

    _setvideomode( _DEFAULTMODE );

}



Classification : PC Graphics
Systems : DOS, QNX













_pg_setstyleset



Synopsis : #include <pgchart.h>

              void _FAR _pg_setstyleset( unsigned short _FAR *style );



Description : The _pg_setstyleset function retrieves the internal style-set of the presentation graphics system. The style-set is a set of line styles used for drawing window borders and grid-lines. The argument style is an array containing the new style-set.





Returns : The _pg_setstyleset function does not return a value.





See Also : _pg_defaultchart, _pg_initchart, _pg_chart, _pg_chartpie, _pg_chartscatter, _pg_getstyleset, _pg_resetstyleset



Example :

#include <graph.h>

#include <pgchart.h>

#include <string.h>

#include <conio.h>

#define NUM_VALUES     4

char _FAR *categories[NUM_VALUES] = { "Jan", "Feb", "Mar", "Apr" };

float values[NUM_VALUES] = { 20, 45, 30, 25 };

main( )

{
    chartenv     env;

    styleset      style;

    _setvideomode( _VRES16COLOR );

    _pg_initchart( );

    _pg_defaultchart ( &eny, _PG_COLUMNCHART, _PG_PLAINBARS );

    strcpy( eny.maintitle.title, "Column Chart" );



    /* turn on yaxis grid, and use style 2 */

    env.yaxis.grid = 1;

    env.yaxis.gridstyle = 2;



    /* get default style-set and change entry 2 */

    _pg_getstyleset( &style );

    style[2] = 0x8888;



    /* use new style-set */

    _pg_setstyleset( &style );

    _pg_chart ( &env, categories, values, NUM_VALUES );



    /* reset style-set to default */

    _pg_resetstyleset( );

    getch( );

    _setvideomode( _DEFAULTMODE );

}



Classification : PC Graphics
Systems : DOS, QNX













_pg_vlabelchart



Synopsis : #include <pgchart.h>

              short _FAR _pg_vlabelchart( chartenv _FAR *eny,
                                             short x, short y,

                                             short color,

                                             char _FAR *label );


Description : The _pg_vlabelchart function displays the text string label on the chart described by the env chart structure. The string is displayed vertically starting at the point (x, y), relative to the upper left corner of the chart. The color specifies the palette color used to display the string.





Returns : The _pg_vlabelchart function returns zero if successful; otherwise, a non-zero value is returned.





See Also : _pg_defaultchart, _pg_initchart, _pg_chart, _pg_chartpie, _pg_chartscatter, _pg_hlabelchart



Example :

#include <graph.h>

#include <pgchart.h>

#include <string.h>

#include <conio.h>

#define NUM_VALUES     4

char _FAR *categories[NUM_VALUES] = { "Jan", "Feb", "Mar", "Apr" };

float values[NUM_VALUES] = { 20, 45, 30, 25 };

main( )

{
    chartenv     env;

    _setvideomode( _VRES16COLOR );

    _pg_initchart( );

    _pg_defaultchart( &eny, _PG_COLUMNCHART, _PG_PLAINBARS );

    strcpy( env.maintitle.title, "Column Chart" );

    _pg_chart( &env, categories, values, NUM_VALUES );

    _pg_hlabelchart( &env, 64, 32, 1, "Horizontal label" );

    _pg_vlabelchart( &env, 48, 32, 1, "Vertical label" );



    getch( );

    _setvideomode( _DEFAULTMODE );

}



Classification : PC Graphics
Systems : DOS, QNX
