Watcom C Library : _scrolltextwindow, _searchenv, segread, _selectpalette, _setactivepage





Watcom C Library Reference : _scrolltextwindow, _searchenv, segread, _selectpalette, _setactivepage









_scrolltextwindow



Synopsis : #include <graph.h>

              void _FAR _scrolltextwindow( short rows );



Description : The _scrolltextwindow function scrolls the lines in the current text window. A text window is defined with the _settextwindow function. By default, the text window is the entire screen.

The argument rows specifies the number of rows to scroll. A positive value means to scroll the text window up or towards the top of the screen. A negative value means to scroll the text window down or towards the bottom of the screen. Specifying a number of rows greater than the height of the text window is equivalent to clearing the text window with the _clearscreen function.

Two constants are defined that can be used with the _scrolltextwindow function:

Constant	Meaning
_GSCROLLUP	the contents of the text window are scrolled up (towards the top of the screen) by one row
_GSCROLLDOWN	the contents of the text window are scrolled down (towards the bottom of the screen) by one row



Returns : The _scrolltextwindow function does not return a value.





See Also : _settextwindow, _clearscreen, _outtext, _outmem, _settextposition



Example :

#include <conio.h>

#include <graph.h>

#include <stdio.h>

void main( )

{
    int     i;

    char   buf[80];

    _setvideomode( _TEXTC80 );

    _settextwindow( 5, 20, 20, 40 );

    for( i = 1; i <= 10; ++i ) {
        sprintf( buf, "Line %d\n", i );

        _outtext ( buf );

    }

    getch( );

    _scrolltextwindow( _GSCROLLDOWN );

    getch( );

    _scrolltextwindow( _GSCROLLUP );



    getch( );

    _setvideomode( _DEFAULTMODE );

}



Classification : PC Graphics
Systems : DOS, QNX















_searchenv



Synopsis : #include <stdlib.h>

              void searchenv( const char *name, const char *env_var, char *buffer );



Description : The _searchenv function searches for the file specified by name in the list of directories assigned to the environment variable specified by env_var. Common values for env_var are PATH, LIB and INCLUDE.

The current directory is searched first to find the specified file. If the file is not found in the current directory, each of the directories specified by the environment variable is searched.



The full pathname is placed in the buffer pointed to by the argument buffer. If the specified file cannot be found, then buffer will contain an empty string.





Returns : The _searchenv function returns no value.





See Also : getenv, setenv, _splitpath, putenv



Example :

#include <stdio.h>

#include <stdlib.h>

void display_help( FILE *fp )

{
    printf( "display_help T.B.I.\n" );

}



void main( )
{
    FILE   *help_file;

    char   full_path[_MAX_PATH];

    _searchenv( "watcomc.hlp", "PATH", full_path );

    if( full_path[0] == '\0' ) {
        printf( "Unable to find help file\n" );

    } else {
        help_file = fopen( full_path, "r" );

        display_help( help_file );

        fclose( help_file );

    }

}



Classification : WATCOM
Systems : All















segread



Synopsis : #include <i86.h>

              void segread( struct SREGS *seg_regs );



Description : The segread function places the values of the segment registers into the structure located
by seg_regs.





Returns : No value is returned.





See Also : FP_OFF, FP_SEG, MK_FP



Example :

#include <stdio.h>

#include <i86.h>

void main( )

{
    struct SREGS sregs;



    segread( &sregs );

    printf( "Current value of CS is %04X\n", sregs.cs );

}



Classification : WATCOM
Systems : All















_selectpalette



Synopsis : #include <graph.h>

              short _FAR _selectpalette( short palnum );



Description : The _selectpalette function selects the palette indicated by the argument palnum from the color palettes available. This function is only supported by the video modes MRES4COLOR and _MRESNOCOLOR.

Mode _MRES4COLOR supports four palettes of four colors. In each palette, color 0, the background color, can be any of the 16 possible colors. The color values associated with the other three pixel values, (1, 2 and 3), are determined by the selected palette.

The following table outlines the available color palettes:

Palette   Number	Pixel Valuse
	1	2	3
0	green	red	brown
1	cyan	magenta	white
2	light green	light red	yellow
3	light cyan	light magenta	bright white





Returns : The _selectpalette function returns the number of the previously selected palette.





See Also : _setvideomode, _getvideoconfig

Example :

#include <conio.h>

#include <graph.h>

void main( )

{
    int     x, y, pal;

    _setvideomode( _MRES4COLOR );

    for( y = 0; y < 2; ++y ) {

        for( x = 0; x < 2; ++x ) {
            _setcolor( x + 2 * y );

            _rectangle( _GFILLINTERIOR,

                          x * 160, y * 100,

                          ( x + 1 ) * 160, ( y + 1 ) * 100 );

        }

    }

    for( pal = 0; pal < 4; ++pal ) {
        _selectpalette( pal );

        getch( );

    }
    _setvideomode( _DEFAULTMODE );

}



Classification : PC Graphics
Systems : DOS, QNX















_setactivepage



Synopsis : #include <graph.h>

              short _FAR _setactivepage( short pagenum );



Description : The _setactivepage function selects the page (in memory) to which graphics output is written. The page to be selected is given by the pagenum argument.

Only some combinations of video modes and hardware allow multiple pages of graphics to exist. When multiple pages are supported, the active page may differ from the visual page. The graphics information in the visual page determines what is displayed upon the screen. Animation may be accomplished by alternating the visual page. A graphics page can be constructed without affecting the screen by setting the active page to be different than the visual page.

The number of available video pages can be determined by using the _getvideoconfig function. The default video page is 0.





Returns : The _setactivepage function returns the number of the previous page when the active page is set successfully; otherwise, a negative number is returned.





See Also : _getactivepage, _setvisualpage, _getvisualpage, _getvideoconfig



Example :

#include <conio.h>

#include <graph.h>

void main( )

{
    int     old_apage;

    int     old_vpage;

    _setvideomode( _HRES16COLOR );

    old_apage = _getactivepage( );

    old_vpage = _getvisualpage( );



    /* draw an ellipse on page 0 */

    _setactivepage( 0 );

    _setvisualpage( 0 );

    _ellipse( _GFILLINTERIOR, 100, 50, 540, 150 );



    /* draw a rectangle on page 1 */

    _setactivepage( 1 );

    _rectangle( _GFILLINTERIOR, 100, 50, 540, 150 );

    getch( );



    /* display page 1 */

    _setvisualpage( 1 );

    getch( );



    _setactivepage( old_apage );

    _setvisualpage( old_vpage );

    _setvideomode( _DEFAULTMODE );

}



Classification : PC Graphics
Systems : DOS, QNX
